Navigator items can easily be added. Behavior of editor and other parts can directly be changed from the navigator.
In this example, an item is added which provides a way to launch an List/Detail editor with a query of all customers of USA with new features.
Use modified query as shown in complete query page.
Add following XML lines where your want the new item to appear:
<item label="List/Detail customers of USA" image="#IMG(adi://org.adichatz.engine/./IMG_QUERY.png)" id="customerUSAQUERY">
<params>
<param value="adi://myproject/./country" id="MESSAGE_BUNDLE"/>
<param id="ICON_URI" value="platform:/plugin/org.adichatz.engine/resources/icons/IMG_QUERY.png"/>
<param id="TITLE" value="List/Detail customers of USA"/>
<param id="TOOL_TIP_TEXT" value="#MSG(adichatzGroupNavigator,customerQueryEditorToolTipText)"/>
<param id="RESOURCE_BUNDLE" value="adi://myproject/./customer"/>
<param xsi:type="listDetailContentProviderType" adiResourceURI="adi://myproject/model.customer/CustomerQUERY" id="CONTENT_PROVIDER" preferenceURI="preferenceName://usa"/>
<param id="ADI_RESOURCE_URI" value="adi://org.adichatz.jpa/query/ListDetailQueryForm"/>
<param id="TABLE_RESOURCE_URI" value="adi://myproject/model.customer/CustomerTI"/>
<param id="DETAIL_RESOURCE_URI" value="adi://myproject/model.customer/CustomerDI"/>
<param id="DUPLICATE_EDITOR" value="true"/>
<param id="ADD_EDITOR_TOOLBAR" value="true"/>
</params>
<customizations>
<tabular refreshAtStart="true" background="#COLOR(SWT.COLOR_TITLE_BACKGROUND_GRADIENT)" id="tableInclude:table"/>
<sashForm id="ListDetailSashForm" orientation="SWT.HORIZONTAL" weights="3,1"/>
<section id="detailInclude:detailContainer">
<listeners>
<listener listenerTypes="BEFORE_SYNCHRONIZE" id="beforeSynchronize">
<code>reinitLayout(controller, true);</code>
</listener>
</listeners>
</section>
<composite id="detailInclude:fieldsComposite">
<layout layoutConstraints="wrap 4" columnConstraints="[align right]10[grow,fill]25[align right]10[grow,fill]"/>
</composite>
<action id="masterDetailTBM:changeOrientationAction">
<listeners>
<listener listenerTypes="PRE_RUN" id="preRun">
<code>reinitLayout(controller, false);</code>
</listener>
</listeners>
</action>
<additionalCode>import org.adichatz.engine.controller.collection.SashFormController
import org.adichatz.engine.controller.AWidgetController
import org.eclipse.swt.SWT
import org.adichatz.engine.controller.collection.SectionController
import net.miginfocom.swt.MigLayout
private void reinitLayout(AWidgetController controller, boolean inverse) {
SashFormController sashFormController = (SashFormController) controller.getRootCore().getFromRegister("ListDetailSashForm");
SectionController sectionController = (SectionController) controller.getRootCore().getFromRegister("detailInclude:detailContainer");
if (null != sectionController.getControl()) {
boolean horizontal = SWT.HORIZONTAL == sashFormController.getControl().getOrientation();
horizontal = inverse ? !horizontal : horizontal;
if (horizontal)
sectionController.getComposite().setLayout(new MigLayout("wrap 4", "[fill, align right]10[fill,grow]25[align right]10[fill,grow]"));
else
sectionController.getComposite().setLayout(new MigLayout("wrap 2", "[fill, align right]10[fill,grow]"));
}}</additionalCode>
</customizations>
</item>
Remark:
The query 'adi://myproject/model.customer/CustomerQUERY' must contains all needed jointures (as address, address.city…) as shown in page complete query.
Explanations:
Lines 3-13: Lists needed parameters for launching the List/Detail part:
Lines 16-50: Defines new behavior on ui components:
